Specification :
Wavelength 810nm±10 Operation Current ＜500mA Output power 200 mw+/- 10% Operational mode Continue/pulse(10Hz) Time set 2J – 10 Seconds 4J –20 seconds 8J – 40 Seconds 16J – 80 seconds 32J – 160 seconds Supply voltage 110V -240V/±50Hz Guide Light Three 450nm visible blue LEDs Duty Cycle 100% (Continuous mode) Treatment Area at Tip 8mm Laser probe size Φ37×140 mm Machine size 190×135×60(mm) Package size 290×205×90(mm) Laser class ⅢB Net weight 0.6kg Gross weight 1.35kg
Benefits of Low Level Laser Therapy
1、Reduce use of pediatric anesthetic.
2、Eliminate edema or decrease pain and inflammation.
3、Decrease need for drugs often associated with side effects.
4、Stimulate fibroblasts, osteoblasts and odontoblasts.
5、Accelerate orthodontic mobility.
Operation：
1、 Connection 110V -240V power supply.
2、 Take the Plug of the laser to the interface USB of the Machine.
3、 Press the “POWER” button: connected the laser power supply, blue LED indicator light, the laser machine into the preparatory working
condition.
4、 Choose the “MODE” button: A, the button up, the mode is continuous output.
5、 The standard time adjustment button: divide into 10、20、40、80、160sec.
6、Step adjustment.
7、 The laser working button: when the working methods, time setting is completed, take the laser probe to the focus, this time can press
the red button on the laser probe, the laser machine and the buzzer work at the same time, when the laser machine stop working,
the buzzer prompt with a long noise for the ending.
8、 The extend time button: if you want to extend the irradiate time, first press the “TIME” button, then take the time adjustment to
160sec,the time of irradiate can extend to 320sec.
